Controller Essentials: PREWIRED (FD) Bundle inc SurRon Style Throttle w Choice of Grips, Key Voltmeter & 3 Speed

3/29:  Kunray Kit owners—I highly recommend adding our Gen 2 replacement wire harness … unless you like re-wiring their altered harness.  😂

Need it all?  Premium throttle, key voltmeter, and 3 speed switch PREWIRED for your FarDriver?  All components are approx 100cm in length, so no need to extend!

Continuous improvement and choices.  That's what we're all about at E-Conic!  Metal housing, more robust POTTED internals (not all SurRon style throttles are created equal), smooth operation, and PREWIRED (100cm) for Fardriver!

Throttle comes with simple 2.8mm, 3 pin connection--simply plug it in to the throttle port of your FarDriver harness & go!  Several ProTaper & Domino A360 grip options!

Note:  DISCONNECT battery when wiring up key voltmeter.  Key Voltmeter--plug two pin voltmeter plug into the two pin RED connector on FarDriver harness.  The one pin connector goes to the one pin ORANGE key lock wire on FarDriver.  3 Speed plugs into the 3 pin BLUE connector on FarDriver harness.  Throttle goes into the WHITE 3 pin connector.

Always check the pins to ensure alignment--never force a connector.

Prewired items only work with the normal FD harness.  The Kunray controllers alter the normal FD harness.  You will need to depin the orange wire from their 2 pin connector and wire it direct to the red wire from the key voltmeter.

If your harness is for an encoder that has a 9 pin, 8 pin, and 6 pin Furukawa connector on the primary harness, this will NOT work.  Normal encoder harnesses only use one 8 pin Furukawa
